The Mosmatic DKS Swivel Coupling 70.054 is a professional-grade, high-pressure swivel engineered for hose connections, quick coupling systems, and cleaning equipment. Constructed from nickel-plated brass, this swivel is built to resist corrosion and deliver long-lasting, dependable performance in industrial environments.
It features a single thrust ball bearing and a high-performance ceramic seal system for smooth rotation and effective sealing under high pressure. A flange design allows for quick and secure installation, while integrated weep holes provide an early warning of seal wear or failure to support proactive maintenance.
This model includes a Quick Connect Thread In of M21x1.5 F and a Thread Out of 3/8" NPTF, with a nominal width of ¼". Designed to handle up to 3600 PSI, 30 RPM, and 250°F, the 70.054 swivel supports media within a pH range of 3–12 and 10-micron filtered compressed air up to 290 PSI.
Applications
-
High-pressure hose and cleaning equipment
-
Quick connect couplings in industrial systems
-
Surface cleaners and rotating spray nozzles
-
Car wash equipment and maintenance setups
-
Pneumatic tool and compressed air systems
-
Commercial and industrial pressure washing
Features
-
Corrosion-resistant nickel-plated brass body
-
Long-life ceramic seal system
-
Single thrust ball bearing for smooth operation
-
Flange design for easy, stable installation
-
Weep holes for seal failure indication
-
Thread In: M21x1.5 F | Thread Out: 3/8" NPTF
-
Nominal Width (NW): ¼"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Overall Diameter: 1.34" | Length: 2.08"
-
Compatible with pH 3–12 media and 10-micron filtered air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M21X1.5F
Thread Out: G2 3/8"NPTF
Nominal Width (NW): ¼"
Wrench Size 1 (SW1): 0.87"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 2.08
Length 2 (L2):
Weight: 3.6 oz
The Mosmatic DKS 90° Swivel Coupling 70.582 is a high-quality, right-angle swivel designed for high-pressure cleaning, hose connections, and quick coupling applications where space-saving flexibility is essential. Constructed from nickel-plated brass, this swivel offers exceptional durability, corrosion resistance, and reliable performance in industrial and commercial environments.
This 90-degree swivel features a single thrust ball bearing for smooth rotational movement and an advanced ceramic seal system to ensure long-lasting, leak-free operation. Its flanged design allows for easy and secure installation, while integrated weep holes provide early visual indication of seal failure, promoting proactive maintenance.
The 70.582 model is equipped with a Quick Connect Thread In of M22x1.5F, a nominal width (NW) of 7/32", and supports high-pressure systems up to 3600 PSI. It operates effectively at a maximum temperature of 250°F and a rotational speed of up to 30 RPM. Compatible with a range of media, including pH 3–12 and 10-micron filtered compressed air up to 290 PSI.
Applications
-
High-pressure hose connections in tight or angled spaces
-
Industrial and commercial cleaning systems
-
Quick-connect pressure washer fittings
-
Rotary surface cleaners and spray tools
-
Pneumatic and compressed air tool systems
-
Car wash installations and detailing setups
Features
-
Durable nickel-plated brass construction for corrosion resistance
-
90° swivel design for optimal flexibility in limited spaces
-
Smooth rotation with single thrust ball bearing
-
Long-lasting ceramic seal system for leak protection
-
Flanged design for easy and secure installation
-
Seal failure warning through integrated weep holes
-
Thread In: M22x1.5F
-
Nominal Width (NW): 7/32"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Overall Diameter: 1.34" | Overall Length: 1.97"
-
Suitable for pH 3–12 media and 10-micron filtered compressed air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M22X1.5F
Nominal Width (NW): 7/32"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 1.97
Weight: 5.7 oz
The Mosmatic 32.915 DGVI Swivel is a precision-engineered swivel designed to improve hose mobility and reduce operator fatigue in paint spray guns, HP-guns, and multi-directional cleaning systems. Built from brass, nickel-plated components, and stainless steel, it ensures high durability and consistent performance in high-pressure environments.
This swivel features a 1/4" NPTF inlet, 1/4" NPTM outlet, a nominal width of 1/4", and an overall length of 4.45". It includes a single thrust ball bearing, a reinforced inner shaft, and is maintenance-free for extended reliability. The integrated NBR O-ring seal (with optional EPDM or FKM) delivers leak-free operation. Rated up to 4000 PSI, 30 RPM, and 250°F, this swivel is ideal for heavy-duty, multi-angle usage.
Applications
-
Paint spray guns and industrial coating systems
-
HP-guns for pressure washing
-
Multi-directional hose assemblies
-
Automotive, marine, and industrial cleaning setups
-
High-pressure fluid delivery systems requiring flexibility
Key Features
-
Thread Inlet: 1/4" NPTF | Thread Outlet: 1/4" NPTM
-
Overall Length: 4.45" | Nominal Width: 1/4"
-
Made from brass, nickel-plated components, and stainless steel
-
360° swivel articulation for full-range hose mobility
-
Single thrust ball bearing for smooth rotation
-
Reinforced inner shaft for added strength
-
Maintenance-free design for long-term performance
-
NBR O-ring seal (EPDM/FKM optional)
-
Rated up to 4000 PSI, 30 RPM, and 250°F
Specs
Pressure: 4000 psi
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, Nickel plated, Stainless Steel
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread IN: 1/4"NPTF
Thread OUT: 1/4"M
Nominal Width (NW): 1/4"
Wrench Size 1 (SW1): 0.75
Wrench Size 2 (SW2): 0.67
Length 1 (L1) (overall length) : 4.45
Length 2 (L2): 0.90
Length 3 (L3): 2.00
Weight: 15.0 oz
The Mosmatic DGV Swivel 32.554 is a high-performance brass, nickel-plated swivel engineered for high-pressure guns, hose connections, and hydraulic systems. Designed for tangle-free operation and live rotation under full pressure, it features a compact, robust construction. This swivel includes a single thrust ball bearing and an O-ring NBR seal system (optional EBDM or FKM) for long-lasting sealing performance. It is corrosion resistant, maintenance free, and ideal for a wide range of industrial and commercial applications.
Applications
-
High-pressure HP-Guns
-
Hose connections and reel systems
-
Hydraulic and pneumatic systems
-
Car washes and cleaning systems
Features
-
Material: Brass, nickel-plated
-
Thread IN (G1): 1/4" NPTM
-
Thread OUT (G2): 3/8" NPTF
-
Overall Length: 2.71"
-
Nominal Width (NW): 1/4"
-
Wrench Size (SW): 0.94"
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
-
Seal System: O-ring NBR (optional EBDM or FKM)
-
Bearing Type: 1x thrust ball bearing
-
Key Benefits: Maintenance free, compact design, corrosion resistant
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
Thread Out: G2 3/8" NPTF
Nominal Width (NW): 1/4"
Wrench Size 1 (SW1): 0.94"
Wrench Size 2 (SW2): 0.87"
Length 1 (L1) (overall length) : 2.71"
Length 2 (L2): 0.39"
Weight: 5.6 oz
The Mosmatic DGV Swivel 32.852 is a brass, nickel-plated swivel designed for high-pressure and hydraulic applications where reliable, low-torque rotation is essential. Built with a single thrust ball bearing and a durable O-ring NBR seal system (upgradeable to EBDM or FKM), this swivel ensures smooth live rotation under pressure, durability, and corrosion resistance in demanding environments. Engineered for longevity and zero-maintenance, it’s a trusted component for hose connections and HP-Gun setups.
Applications
-
High-pressure spray guns
-
Hydraulic hose connections
-
Hose reel systems
-
Pneumatic and industrial fluid applications
-
Tangle-free setups for pressurized systems
Features
-
Material: Brass, nickel plated
-
Thread IN (G1): 3/8" NPTM
-
Thread OUT (G2): 3/8" NPTF
-
Overall Length: 2.87"
-
Nominal Width (NW): 3/8"
-
Wrench Size (SW): 1.06"
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
-
Seal System: O-ring NBR (optional: EBDM or FKM)
-
Bearing: 1x thrust ball bearing
-
Key Benefits: Corrosion resistant, compact design, live rotation, maintenance free
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 3/8" NPTM
Thread Out: G2 3/8" NPTF
Nominal Width (NW): 3/8"
Wrench Size 1 (SW1): 1.06"
Wrench Size 2 (SW2): 0.87"
Length 1 (L1) (overall length) : 2.87"
Length 2 (L2): 0.43"
Weight: 6.4 oz
The Mosmatic DGV Swivel 32.569 is a brass, nickel-plated swivel built for superior performance in high-pressure systems (box of 25). Designed for HP-Guns, hydraulic applications, and hose connections, it provides smooth and reliable rotation under pressure. The single thrust ball bearing and O-ring NBR seal (with optional EBDM or FKM upgrades) offer leak-free operation and extended service life. This swivel is ideal for keeping hoses tangle-free while ensuring optimal flow and control, all in a compact, corrosion-resistant, and maintenance-free design.
(Box of 25)
Applications
-
High-pressure spray guns
-
Hydraulic and pneumatic hose connections
-
Industrial fluid handling
-
Hose reels and car wash systems
-
Anti-kink swivel joints
Features
-
Material: Brass, nickel plated
-
Thread IN (G1): 3/8" NPTF
-
Thread OUT (G2): 3/8" NPTF
-
Overall Length: 2.87"
-
Nominal Width (NW): 1/4"
-
Wrench Size (SW): 0.94"
-
Max Pressure: 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
-
Seal System: O-ring NBR (optional: EBDM or FKM)
-
Bearing Type: 1x thrust ball bearing
-
Design Benefits: Compact, corrosion-resistant, tangle-free, maintenance-free
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 3/8" NPTF
Thread Out: G2 3/8" NPTF
Nominal Width (NW): 1/4"
Wrench Size 1 (SW1): 0.94"
Wrench Size 2 (SW2): 0.87"
Length 1 (L1) (overall length) : 2.87"
Weight: 7.1 oz
The Mosmatic DKS Swivel Coupling 70.132 is a precision-engineered, high-pressure swivel coupling designed for hose connections, cleaning systems, and quick coupling applications. Manufactured from nickel-plated brass, this swivel provides superior corrosion resistance and long-lasting performance in industrial and commercial environments.
The unit features a single thrust ball bearing and an advanced ceramic seal system, ensuring smooth rotation and effective sealing even under high-pressure conditions. The integrated flange offers easy, secure installation, while built-in weep holes serve as an early warning system for seal failure, helping to maintain operational efficiency.
This model includes a Quick Connect Thread In of M22x1.5F, with a nominal width (NW) of 7/32", an overall diameter of 1.34", and a length of 2.34". Rated for up to 3600 PSI, with a maximum temperature of 250°F and a maximum speed of 30 RPM, the DKS 70.132 is suitable for media within a pH range of 3–12 and 10-micron filtered compressed air up to 290 PSI.
Applications
-
Industrial high-pressure cleaning systems
-
Hose connection assemblies and quick coupling setups
-
Surface cleaners and rotating spray tools
-
Car wash systems and detailing equipment
-
Pneumatic tool connections and compressed air lines
-
Pressure washing accessories in commercial environments
Features
-
Heavy-duty nickel-plated brass construction for corrosion resistance
-
Long-life ceramic seal system for reliable sealing performance
-
Smooth rotation with single thrust ball bearing
-
Easy, stable installation with integrated flange design
-
Seal failure warning through weep holes for proactive maintenance
-
Thread In: M22x1.5F
-
Nominal Width (NW): 7/32"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Overall Diameter: 1.34" | Overall Length: 2.34"
-
Compatible with pH 3–12 media and 10-micron filtered compressed air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M22X1.5F
Nominal Width (NW): 7/32"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 2.34
Weight: 3.0 oz
The Mosmatic DKS Swivel Coupling 70.139 is a high-performance, nickel-plated brass swivel coupling designed for high-pressure cleaning, hose connections, and quick coupling applications. Built for reliability and efficiency, this swivel delivers superior corrosion resistance and smooth rotational function, making it ideal for industrial and commercial environments.
The swivel features a single thrust ball bearing and a precision-engineered ceramic seal system for leak-free operation and extended service life. A flanged design ensures easy and secure installation, while integrated weep holes act as an early warning system for seal failure, helping to prevent unexpected downtime.
With a Quick Connect Thread In of M22x1.5F and a Nominal Width (NW) of ¼", this swivel coupling supports high-pressure systems up to 3600 PSI, operating at temperatures up to 250°F and a maximum speed of 30 RPM. Suitable for media with a pH range of 3–12 and 10-micron filtered compressed air up to 290 PSI.
Applications
-
High-pressure hose assemblies
-
Industrial cleaning and spraying systems
-
Quick-connect setups for pressure washers
-
Rotary nozzles and surface cleaning tools
-
Car wash equipment and detailing systems
-
Pneumatic and compressed air tool connections
Features
-
Durable nickel-plated brass construction for corrosion resistance
-
Advanced ceramic seal system for long-lasting performance
-
Single thrust ball bearing for smooth, reliable rotation
-
Flanged design for easy and stable installation
-
Integrated weep holes for early seal failure detection
-
Thread In: M22x1.5F
-
Nominal Width (NW): ¼"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Dimensions: 1.34" overall diameter | 2.42" overall length
-
Compatible with pH 3–12 media and 10-micron filtered compressed air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M22X1.5F
Nominal Width (NW): ¼"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 2.42
Weight: 3.0 oz
The Mosmatic DKS Swivel Coupling 70.131 is a high-precision, nickel-plated brass swivel designed for high-pressure cleaning systems, hose connections, and quick-coupling applications. With a compact build and premium materials, it ensures exceptional durability and resistance to corrosion in industrial and commercial environments.
This model includes a single thrust ball bearing and a ceramic seal system, providing smooth rotation and long-term leak protection under pressure. The integrated flange design simplifies installation, while built-in weep holes serve as a seal failure warning system to support preventative maintenance.
With a Quick Connect Thread In of M22x1.5F, a nominal width (NW) of 1/8", and an overall length of 2.26", this swivel is rated for up to 3600 PSI and operates at temperatures up to 250°F. It's compatible with a broad range of media, including pH 3–12 and 10-micron filtered compressed air up to 290 PSI.
Applications
-
Compact high-pressure cleaning equipment
-
Industrial hose and fitting systems
-
Surface cleaners and small rotating nozzles
-
Precision pneumatic tools and compressed air lines
-
Car wash accessories and detailing systems
-
Quick-connect hose setups in commercial environments
Key Features
-
Durable, corrosion-resistant nickel-plated brass construction
-
Single thrust ball bearing for smooth rotational movement
-
Advanced ceramic seal system for reliable sealing
-
Integrated flange for fast and secure installation
-
Weep holes for visual seal failure indication
-
Thread In: M22x1.5F
-
Nominal Width (NW): 1/8"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Overall Diameter: 1.34" | Overall Length: 2.26"
-
Compatible with pH 3–12 media and 10-micron filtered compressed air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M22X1.5F
Nominal Width (NW): 1⁄8"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 2.26
Length 2 (L2):
Weight: 2.8 oz
The Mosmatic DKS Swivel Coupling 70.053 is a precision-engineered, high-pressure swivel designed for demanding industrial and commercial cleaning applications. Constructed from corrosion-resistant, nickel-plated brass, this swivel ensures reliability and long service life under continuous use.
Equipped with a single thrust ball bearing and a robust ceramic seal system, it delivers smooth rotation and excellent leak protection. A flange simplifies installation, while integrated weep holes provide a seal failure warning for proactive maintenance. This model features a Quick Connect Thread In of M21x1.5 F and a Thread Out of 3/8" NPTM, making it compatible with a wide range of hose systems and equipment.
Rated for up to 3600 PSI and capable of withstanding temperatures up to 250°F, it’s built for tough environments and supports media in the pH 3–12 range with 10-micron filtered compressed air up to 290 PSI.
Applications
-
High-pressure hose and cleaning systems
-
Industrial and commercial washdown equipment
-
Pneumatic tool connections
-
Surface cleaners and rotary arms
-
Quick-connect fittings in pressure washing setups
-
Car wash installations
Features
-
High-quality nickel-plated brass construction
-
Smooth rotation with single thrust ball bearing
-
Long-life ceramic seal system
-
Flanged design for easy and secure installation
-
Seal failure warning via built-in weep holes
-
Thread In: M21x1.5 F" | Thread Out: 3/8" NPTM
-
Nominal Width (NW): ¼"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Dimensions: 1.34" diameter | 1.80" overall length
-
Compatible with pH 3–12 media and 10-micron filtered air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M21X1.5F
Thread Out: G2 3/8"NPTM
Nominal Width (NW): ¼"
Wrench Size 1 (SW1): 0.75"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 1.80
Length 2 (L2): 0.47
Weight: 3.6 oz
The Mosmatic DKS Swivel Coupling 70.051 is a high-performance, nickel-plated brass swivel designed for high-pressure cleaning and hose connection systems. Engineered with a single thrust ball bearing and a precision ceramic seal system, it ensures smooth rotation and leak-resistant operation. A built-in flange allows for easy installation, while integrated weep holes provide early warning of seal failure to prevent downtime.
With a high-pressure capacity of up to 3600 PSI and a max temperature tolerance of 250°F, this swivel coupling is built to withstand rigorous industrial use. It features a quick-connect M21x1.5 F thread in and a ¼" NPTM thread out, offering compatibility across a range of applications. Supporting a nominal width of ¼", and a max speed of 30 RPM, it’s optimized for pH 3–12 media and 10-micron filtered compressed air up to 290 PSI.
Applications
-
High-pressure cleaning equipment
-
Industrial hose connections
-
Quick-connect systems
-
Surface cleaners and rotary arms
-
Car wash systems
-
Pneumatic tool connections
Features
-
Durable nickel-plated brass construction
-
Single thrust ball bearing for smooth rotation
-
Advanced ceramic seal system for enhanced durability
-
Integrated flange for easy installation
-
Seal failure indicator via weep holes
-
Thread In: M21x1.5 F | Thread Out: ¼" NPTM
-
Nominal Width (NW): ¼"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Overall Diameter: 1.34" | Length: 1.76"
-
Media compatibility: pH 3–12, 10-micron filtered air up to 290 PSI
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M21X1.5F
Thread Out: G2 1/4"NPTM
Nominal Width (NW): ¼"
Wrench Size 1 (SW1): 0.67"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 1.76
Length 2 (L2): 0.43
Weight: 3.6 oz
The Mosmatic DKS Swivel Coupling 70.052 is a high-quality, heavy-duty swivel coupling designed for high-pressure cleaning, hose connections, and quick coupling systems. Built from nickel-plated brass, this durable swivel delivers exceptional corrosion resistance and long-lasting performance in tough industrial and commercial environments.
Engineered with a single thrust ball bearing and a ceramic seal system, the 70.052 model ensures smooth rotation and dependable sealing under pressure. A built-in flange allows for secure, straightforward installation, and integrated weep holes serve as early seal failure indicators to minimize downtime and prevent damage.
Featuring a Quick Connect Thread In of M21x1.5 F and a Thread Out of ¼" NPTF, this swivel is optimized for high-pressure systems operating up to 3600 PSI and temperatures up to 250°F. It supports a wide range of media with a pH range of 3–12 and 10-micron filtered compressed air up to 290 PSI.
Applications
-
High-pressure cleaning equipment
-
Industrial hose and coupling systems
-
Pressure washer accessories
-
Rotary surface cleaners and nozzles
-
Car wash systems
-
Pneumatic tool connections
Features
-
Rugged nickel-plated brass construction
-
Ceramic seal system for enhanced durability
-
Smooth operation via single thrust ball bearing
-
Flanged design for easy and secure installation
-
Weep holes for early seal failure detection
-
Thread In: M21x1.5 F | Thread Out: ¼" NPTF
-
Nominal Width (NW): ¼"
-
Max Pressure: 3600 PSI
-
Max Temperature: 250°F
-
Max RPM: 30
-
Dimensions: 1.34" diameter | 1.96" overall length
-
Compatible with pH 3–12 media and 10-micron filtered air (290 PSI)
Specs
Pressure: 3600 psi
Temperature: 250°
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR
Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)
Thread In: G1 M21X1.5F
Thread Out: G2 1/4"NPTF
Nominal Width (NW): ¼"
Wrench Size 1 (SW1): 0.75"
Diameter (D) (overall diameter): 1.34"
Length 1 (L1) (overall length) : 1.96
Length 2 (L2):
Weight: 3.6 oz
The Mosmatic 32.906 DGVI Swivel is a high-performance swivel joint engineered to enhance the flexibility and handling of paint spray guns, HP-guns, and multi-directional hose setups. Constructed from brass, nickel-plated components, and stainless steel, this swivel ensures long-lasting durability and smooth operation in high-pressure environments.
Designed with a 1/4" NPTF inlet and 1/8" NPTM outlet, the swivel offers a nominal width of 1/4" and a compact length of 4.17". It features a single thrust ball bearing system, a reinforced inner shaft, and a maintenance-free design. The NBR O-ring seal (optional EPDM or FKM) ensures leak-free performance, while its full 360° articulation supports up to 4000 PSI, 30 RPM, and 250°F, making it ideal for professional applications.
Applications
-
Paint spray guns and airless spraying systems
-
HP-guns for pressure washing
-
Multi-directional hose assemblies
-
Industrial and automotive refinishing equipment
-
High-pressure fluid delivery in confined or mobile setups
Key Features
-
Made from brass, nickel-plated, and stainless steel
-
Thread Inlet: 1/4" NPTF | Thread Outlet: 1/8" NPTM
-
Overall Length: 4.17" | Nominal Width: 1/4"
-
Rated for 4000 PSI, 30 RPM, and 250°F max temperature
-
Includes NBR O-ring seal system (EPDM and FKM optional)
-
Single thrust ball bearing for smooth swivel action
-
Reinforced inner shaft for added strength
-
Maintenance-free, full 360° swivel design
Specs
Pressure: 4000 psi
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, Nickel plated, Stainless Steel
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread IN: 1/4"NPTF
Thread OUT: 1/8"M
Nominal Width (NW): 1/4"
Wrench Size 1 (SW1): 0.75
Wrench Size 2 (SW2): 0.40
Length 1 (L1) (overall length) : 4.17
Length 2 (L2): 0.60
Length 3 (L3): 2.00
Weight: 13.8 oz
The Mosmatic DGV Swivel 32.553 is a high-performance brass, nickel-plated swivel engineered for high-pressure spray guns, hose connections, and hydraulic systems. It offers live rotation under full pressure with a durable thrust ball bearing and O-ring NBR seal system (with EBDM or FKM options). The compact and robust design ensures superior reliability, corrosion resistance, and maintenance-free operation for extended life in demanding environments.
Applications
-
High-pressure gun assemblies
-
Hose connections and reels
-
Industrial hydraulics
-
Car wash and cleaning systems
-
Tangle-free hose management
Features
-
Material: Brass, nickel plated
-
Thread In/Out: 1/4" NPTM to 3/8" NPTM
-
Pressure Capacity: Up to 4000 PSI
-
Max RPM: 30
-
Max Temperature: 250°F
-
Seal Type: O-ring NBR (optional EBDM or FKM)
-
Bearing: Thrust ball bearing
-
Corrosion Resistant: Long-lasting performance
-
Maintenance-Free: Ready for continuous use
-
Compact Design: Overall length of 2.44"
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 1/4" NPTM
Thread Out: G2 3/8" NPTM
Nominal Width (NW): 1/4"
Wrench Size 1 (SW1): 0.94"
Wrench Size 2 (SW2): 0.75"
Length 1 (L1) (overall length) : 2.44"
Length 2 (L2): 0.39"
Length 3 (L3): 0.47"
Weight: 4.9 oz
Showing 44/44
