The Mosmatic DGG Swivel 33.463 (90 Degrees) is a brass, nickel-plated high-pressure swivel engineered for efficient operation in self-rotating and automated cleaning systems. With its compact 90° design and robust construction, it’s the ideal solution for tire cleaning, parts washers, and surface cleaners in industrial or commercial environments.

This swivel features a triple bearing system consisting of 2x radial ball bearings and 1x thrust ball bearing, enabling smooth, controlled rotation under pressure. It includes a reliable O-ring NBR seal system, with optional EPDM or FKM seals for enhanced chemical resistance. Built for corrosion resistance and maintenance-free performance, the DGG 33.463 is designed to withstand high RPMs and pressures in demanding applications.

Applications

• High-pressure rotating cleaning systems

• Tire and underbody washing equipment

• Industrial parts washers

• Surface cleaners and rotating nozzles

• Automated washing systems

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Type: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): G3/8" M

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 G3/8" M

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Length 2 (L2): 0.39"

Weight: 12.1 oz

The Mosmatic DKS Swivel Coupling 70.152 is a high-quality, precision-engineered swivel designed for high-pressure cleaning, hose connections, and quick coupling applications. Manufactured from durable, nickel-plated brass, this swivel is corrosion-resistant and built for long-lasting performance in industrial and commercial environments.

Featuring a single thrust ball bearing and a robust ceramic seal system, the 70.152 ensures smooth 360° rotation and leak-resistant operation under pressure. Its flanged design enables easy, secure installation, while integrated weep holes provide a built-in visual indicator of seal wear or failure—helping to reduce unexpected downtime.

This model includes a Quick Connect Thread In of M22x1.5 F and a Thread Out of ¼" NPTF, with a nominal width of ¼". Designed for up to 3600 PSI, it also withstands temperatures up to 250°F, supports speeds of up to 30 RPM, and is compatible with media in the pH 3–12 range as well as 10-micron filtered compressed air (290 PSI).

Applications

• High-pressure hose and spray systems

• Industrial and commercial cleaning equipment

• Quick-connect fittings for pressure washers

• Surface cleaners and rotary spray arms

• Car wash installations and systems

• Pneumatic and compressed air tool connections

Key Features

• Nickel-plated brass construction for durability and corrosion resistance

• High-performance ceramic seal system

• Single thrust ball bearing for smooth, controlled rotation

• Flanged design for easy and secure installation

• Weep holes for early seal failure detection

• Thread In: M22x1.5 F | Thread Out: ¼" NPTF

• Nominal Width (NW): ¼"

• Max Pressure: 3600 PSI

• Max Temperature: 250°F

• Max RPM: 30

• Overall Diameter: 1.34" | Overall Length: 1.96"

• Compatible with pH 3–12 media and 10-micron filtered air (290 PSI)

Specs

Pressure: 3600 psi

Temperature: 250°

RPM: max 30 rpm

Material Type: Brass, nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR

Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)

Thread In: G1 M22X1.5F

Thread Out: G2 1/4"NPTF

Nominal Width (NW): ¼"

Wrench Size 1 (SW1): 0.75"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 1.96

Length 2 (L2):

Weight: 3.7 oz

The Mosmatic DGVI Swivel 32.768 is a high-performance stainless steel swivel engineered for high-pressure hose reels, hydraulics, and HP-Guns. With 3/8" NPTF inlet and 3/8" NPTM outlet threads, this swivel allows for smooth, live rotation under maximum pressure, ensuring efficiency and longevity in demanding systems.

Built with a durable single thrust ball bearing and O-ring NBR seal system (with optional EPDM or FKM), the 32.768 is maintenance free and corrosion resistant, providing reliable operation even under extreme conditions.

Applications

• High-pressure hose reels

• Hydraulic systems

• HP-Guns and pressure washers

• Commercial wash equipment

• Tangle-free hose connections

Features

• Material: Full stainless steel body

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTM

• Overall Length: 2.60"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.94"

• Max Pressure: 7300 PSI

• Max RPM: 30

• Max Temperature: 250°F

• Bearing System: 1x thrust ball bearing

• Seal Type: O-ring NBR (optional EPDM or FKM)

• Performance: Live rotation, corrosion-resistant, zero maintenance

Specs

Pressure: 7300 psi (50 MPa)

Temperature: 250°F

RPM: max 30 rpm

Material Type: Stainless steel

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.94"

Wrench Size 2 (SW2): 0.75"

Length 1 (L1) (overall length) : 2.60"

Length 2 (L2): 0.47"

Weight: 5.9 oz

The Mosmatic DGG Swivel 33.151 is a premium nickel-plated brass swivel engineered for high-pressure and self-rotating cleaning systems. Designed for durability and precision, this swivel incorporates a triple bearing system—including two radial ball bearings and one thrust bearing—to ensure optimal performance and reliability.

Its O-ring NBR sealing system (also available in EPDM or FKM) provides flexibility for varied applications and fluid compatibility. With a corrosion-resistant design and maintenance-free construction, the DGG 33.151 is built to meet the rigorous demands of commercial and industrial cleaning systems.

Applications:

• High-pressure self-rotating cleaning systems

• Undercarriage and tire washers

• Industrial parts washers

• Car wash and fleet wash systems

• Factory and equipment cleaning

Key Features:

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: Triple system – 2x radial, 1x thrust

• Mounting: Bulkhead fitting

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 1/4" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.55"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM; 250°F at 30 RPM

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.67"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.55"

Length 2 (L2): 0.43"

Weight: 7.4 oz

The Mosmatic DGG Swivel 33.351 (90 Degrees) is a high-precision, brass, nickel-plated swivel designed for high-pressure, self-rotating cleaning applications. Built to perform in demanding environments like tire washers, parts cleaning systems, and industrial surface cleaners, this swivel ensures longevity and efficiency.

Featuring a compact 90-degree angle design, it includes a triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth, reliable operation. The swivel is sealed with a dependable O-ring NBR system, with optional upgrades to EPDM or FKM for chemical resistance. Designed for corrosion resistance, easy bulkhead mounting, and maintenance-free use, the 33.351 delivers long-term durability and exceptional precision.

Applications

• High-pressure rotating cleaning systems

• Tire and underbody cleaning equipment

• Parts washers and degreasers

• Industrial wash stations

• Surface cleaners and sprayers

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Type: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 1/4" NPTF

• Thread OUT (G2): 1/4" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.71"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting Style: Bulkhead

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.67"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.71"

Length 2 (L2): 0.43"

Weight: 7.8 oz

The Mosmatic DGF Swivel - 35.053 is a robust, high-pressure swivel engineered for precision and durability in demanding cleaning environments. Crafted from brass with a corrosion-resistant nickel-plated finish, this swivel is ideal for use in tire cleaners, parts washers, and self-rotating cleaning equipment. It features a triple bearing system—two radial ball bearings and one thrust ball bearing—for superior rotational performance and extended operational life. An O-ring NBR seal ensures leak-proof performance under high pressure and varying temperatures.

Applications:

• High-pressure cleaning systems

• Self-rotating cleaning equipment

• Parts washers

• Tire cleaning applications

Key Features:

• Brass body with nickel plating for long-term durability

• Triple bearing system: 2x radial + 1x thrust ball bearing

• O-ring NBR seal for reliable performance

• Thread IN: G1 1/4" NPTF | Thread OUT: G2 3/8" NPTM

• Nominal Width (NW): 1.4"

• Overall Diameter: 2.36"

• Overall Length: 1.49"

• Pressure rated up to 4000 PSI

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM / 250°F at 30 RPM

Specs

Pressure: 4000 psi

Temperature: 90°F (at 1,000 rpm) and 250°F (at 30 rpm).

RPM: max 1,000 rpm

Material Type: Brass, nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4"NPTF

Thread Out: G2 3/8"NPTM

Nominal Width (NW): 1.4"

Wrench Size 1 (SW1): 0.87

Wrench Size 2 (SW2): 0.75

Diameter (D) (overall diameter): 2.36

Length 1 (L1) (overall length): 1.49

Length 2 (L2): 0.47

Weight: 11.0oz

The Mosmatic DYL Swivel 56.154 is a robust, high-performance swivel crafted from nickel-plated brass, designed for use in high-speed, high-pressure cleaning systems. Ideal for parts washers, tire cleaners, and rotary equipment, this swivel features a precision triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth and stable rotation. The integrated carbide seal system ensures excellent leak resistance, while the corrosion-resistant construction guarantees long-term durability. With a bulkhead fitting for secure mounting, this swivel is fully maintenance-free and built for demanding industrial applications.

Applications

• High-pressure cleaning systems

• Parts washers

• Tire and wheel cleaning equipment

• High-speed rotary spray tools

• Commercial and industrial wash systems

Key Features

• Durable brass body with corrosion-resistant nickel plating

• Triple bearing system: 2x radial, 1x thrust ball bearing

• Carbide seal system for long-lasting leak protection

• Designed for high-speed, high-pressure operation

• Maintenance-free performance

• Bulkhead fitting for secure, fixed installation

• Thread IN: 3/8" NPTF | Thread OUT: 3/8" NPTF

• Max Pressure: 4000 PSI

• Max RPM: 2000

• Max Temperature: 250°F

• Overall Diameter: 0.98"

• Overall Length: 3.42"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

Specs

Pressure: 4000 psi

Temperature: 250°

RPM: max 2,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless Steel

Seal: Carbide

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTF

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.87"

Length 1 (L1) (overall length) : 3.42"

Diameter (D1): 0.98"

Weight: 8.2 oz

The Mosmatic DXLI Swivel 36.158 is a high-performance stainless steel swivel engineered for high-pressure and high-RPM cleaning systems. Designed for demanding applications such as parts washers, tire cleaning tools, and industrial washing equipment, this swivel offers exceptional durability, rotational stability, and leak resistance. It features a triple bearing system—including two radial ball bearings and one thrust ball bearing—for smooth, reliable operation under continuous use. The ceramic seal system ensures superior performance and longevity, even under extreme pressure. Built with a bulkhead fitting for secure mounting, the DXLI 36.158 is completely maintenance-free and built for long-term efficiency.

Applications

• High-pressure cleaning technology

• Tire and wheel cleaning systems

• Parts washers

• Self-rotating, high-RPM cleaning tools

• Commercial and industrial wash systems

Key Features

• Stainless steel body for top-tier corrosion resistance

• Triple bearing system: 2x radial, 1x thrust ball bearing

• Ceramic seal system for long-lasting, leak-free performance

• Engineered for high-RPM and high-pressure environments

• Bulkhead fitting for secure installation

• Maintenance-free operation for industrial reliability

• Thread IN: 3/8" NPTF | Thread OUT: 3/8" NPTM

• Max Pressure: 2500 PSI (17 MPa)

• Max RPM: 2000

• Temperature Range: 40°F – 250°F

• Overall Diameter: 0.98"

• Overall Length: 3.14"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

Specs

Pressure: 2500 psi (17 MPa)

Temperature: 40°- 250°

RPM: max 2,000 rpm

Material Type: Stainless steel

Inner Part: Stainless steel

Seal: Ceramic

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Length 1 (L1) (overall length) : 3.14"

Length 2 (L2): 0.47"

Diameter (D) (overall diameter): 0.98"

Weight: 6.8 oz

The Mosmatic DXGI Swivel 37.158 is a high-performance stainless steel swivel engineered for high-RPM, self-rotating cleaning applications. Ideal for use in surface cleaners, parts washers, and tire cleaning systems, this swivel delivers precision, long-term durability, and excellent corrosion resistance. It features a robust triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth and consistent rotation. The integrated ceramic seal system provides superior leak protection in high-pressure environments. With a maintenance-free design and secure bulkhead fitting, the DXGI 37.158 is built for demanding industrial use.

Applications

• Surface cleaners

• Parts washers

• Tire and wheel cleaning systems

• High-RPM self-rotating spray tools

• Industrial and commercial pressure washing systems

Key Features

• Corrosion-resistant stainless steel construction

• Triple bearing system: 2x radial, 1x thrust ball bearing

• Ceramic seal system for long-lasting leak protection

• Designed for high-RPM, self-rotating cleaning applications

• Bulkhead fitting for fixed, secure mounting

• Maintenance-free operation

• Thread IN: 3/8" NPTF | Thread OUT: 3/8" NPTM

• Max Pressure: 2500 PSI (17 MPa)

• Max RPM: 2000

• Temperature Range: 40°F – 250°F

• Overall Diameter: 1.42"

• Overall Length: 3.14"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

Specs

Pressure: 2500 psi (17 MPa)

Temperature: 40°- 250°

RPM: max 2,000 rpm

Material Type: Stainless Steel

Inner Part: Stainless Steel

Seal: Ceramic

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.42"

Diameter (D) (overall diameter): 1.42"

Length 1 (L1) (overall length) : 3.14"

Length 2 (L2): 0.47"

Weight: 9.8 oz

The Mosmatic DXG Swivel 37.163 is a premium brass swivel with a corrosion-resistant nickel-plated finish, engineered for high-RPM, self-rotating cleaning systems. Designed for use in surface cleaners, parts washers, and tire cleaning equipment, this swivel delivers smooth operation, precision performance, and long-lasting durability. It features a triple bearing system—two radial ball bearings and one thrust ball bearing—for optimal rotation stability. The integrated ceramic seal system ensures leak-free reliability even under high pressure. With a bulkhead fitting for secure mounting and a maintenance-free design, it's built for industrial-grade performance.

Applications

• Surface cleaners

• Parts washers

• Tire and wheel cleaning systems

• High-RPM self-rotating tools

• Industrial and commercial pressure washing systems

Key Features

• Brass construction with corrosion-resistant nickel plating

• Triple bearing system: 2x radial, 1x thrust ball bearing

• Ceramic seal system for extended leak protection

• Designed for high-RPM, self-rotating cleaning applications

• Maintenance-free performance in demanding environments

• Bulkhead fitting for secure, fixed installation

• Thread IN: 3/8" NPTF | Thread OUT: G3/8" M

• Max Pressure: 2500 PSI (17 MPa)

• Max RPM: 2000

• Temperature Range: 40°F – 250°F

• Overall Diameter: 1.34"

• Overall Length: 3.14"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

Specs

Pressure: 2500 psi (17 MPa)

Temperature: 40°- 250°

RPM: max 2,000 rpm

Material Type: Brass, Nicket plated

Inner Part: Stainless Steel

Seal: Ceramic

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 G3/8"M

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 3.14"

Length 2 (L2): 0.39"

Weight: 9.7 oz

The Mosmatic DXG 90° Swivel 37.353 is a high-quality nickel-plated brass swivel designed for high-RPM, self-rotating cleaning applications. Ideal for use in surface cleaners, parts washers, and tire cleaning systems, this 90-degree swivel offers robust corrosion resistance, precision engineering, and a smooth, maintenance-free operation. It features a triple bearing system—two radial ball bearings and one thrust ball bearing—for exceptional rotation stability. The integrated ceramic seal system ensures long-lasting, leak-proof performance under high pressure. With a secure bulkhead fitting, this swivel is built to withstand the rigors of industrial cleaning environments.

Applications

• Surface cleaners

• Parts washers

• Tire and wheel cleaning tools

• High-RPM self-rotating cleaning equipment

• Industrial and commercial pressure washing

Key Features

• Durable brass body with corrosion-resistant nickel plating

• 90-degree configuration for angled installations

• Triple bearing system: 2x radial, 1x thrust ball bearing

• Ceramic seal system for enhanced leak protection

• Designed for high-RPM self-rotating systems

• Bulkhead fitting for fixed, secure mounting

• Maintenance-free design

• Thread IN: 1/4" NPTF | Thread OUT: 3/8" NPTM

• Max Pressure: 2500 PSI (17 MPa)

• Max RPM: 2000

• Temperature Range: 40°F – 250°F

• Overall Diameter: 1.34"

• Overall Length: 3.30"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

Specs

Pressure: 2500 psi (17 MPa)

Temperature: 40°- 250°

RPM: max 2,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: Ceramic

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 3.30

Length 2 (L2): 0.47

Weight: 9.9 oz

The Mosmatic DXFI Swivel - 38.157 is a premium stainless steel swivel engineered for high-RPM, high-pressure applications in demanding cleaning environments. Designed for surface cleaners, self-rotating tools, tire washers, and industrial parts washers, this swivel provides exceptional durability and smooth performance. Its precision triple bearing system—two radial ball bearings and one thrust ball bearing—ensures reliable, long-lasting rotation. A ceramic seal system offers superior resistance to heat, pressure, and wear. Integrated weep holes provide early seal failure detection, while the flange mount allows for quick, secure installation.

Applications:

• High-RPM self-rotating cleaning tools

• Industrial and commercial surface cleaners

• Tire and wheel cleaning equipment

• Parts washers and degreasing systems

Key Features:

• Durable stainless steel construction for corrosion resistance

• Triple bearing system: 2x radial + 1x thrust ball bearing

• Long-lasting ceramic seal system for high-pressure use

• Weep holes for proactive seal failure detection

• Flange mount for quick and secure installation

• Thread IN: 3/8" NPTF | Thread OUT: 1/4" NPTF

• Nominal Width (NW): 1/4"

• Overall Diameter: 2.36"

• Overall Length: 1.65"

• Max Pressure: 2500 PSI

• Max RPM: 2000

• Temperature Range: 40°F to 250°F

Specs

Pressure: 2500 psi

Temperature: 40°F - 250°

RPM: max 2,000 rpm

Material Type: Brass, Nickel Plated

Inner Part: Stainless steel

Seal: Ceramic

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8"NPTF

Thread Out: G2 3/8"NPTF

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87

Wrench Size 2 (SW2): 0.87

Diameter (D) (overall diameter): 2.36"

Length 1 (L1) (overall length): 1.76

Weight: 10.0oz

The Mosmatic DXF 90° Swivel - 38.353 is a high-efficiency stainless steel swivel designed for high-RPM, high-pressure cleaning applications requiring a 90-degree flow configuration. Ideal for use in surface cleaners, tire washers, parts washers, and self-rotating tools, this swivel delivers long-lasting durability and smooth rotation. It features a precision-engineered triple bearing system—two radial ball bearings and one thrust ball bearing—to ensure stability and longevity in high-speed environments. The ceramic seal system provides exceptional resistance to heat and pressure, while integrated weep holes serve as early indicators of seal failure. The flange mount enables fast, secure installation.

Applications:

• Self-rotating high-RPM cleaning tools

• Industrial and commercial surface cleaners

• Tire and wheel washing equipment

• Parts washers and automated cleaning stations

Key Features:

• 90° swivel design for optimized flow routing

• Stainless steel construction for corrosion resistance

• Triple bearing system: 2x radial + 1x thrust ball bearing

• Long-life ceramic seal system for high-performance use

• Weep holes for early seal failure detection

• Flange mount for quick and secure installation

• Thread IN: 1/4" NPTF | Thread OUT: 3/8" NPTM

• Nominal Width (NW): 1/4"

• Overall Diameter: 2.36"

• Overall Length: 1.49"

• Max Pressure: 2500 PSI

• Max RPM: 2000

• Temperature Range: 40°F to 250°

Specs

Pressure: 2500 psi

Temperature: 40°F - 250°

RPM: max 2,000 rpm

Material Type: Brass, Nickel Plated

Inner Part: Stainless steel

Seal: Ceramic

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4"NPTF

Thread Out: G2 3/8"NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87

Wrench Size 2 (SW2): 0.75

Diameter (D) (overall diameter): 2.36"

Length 1 (L1) (overall length): 1.49

Length 2 (L2): 0.47

Weight: 14.2oz

The Mosmatic DKS Swivel Coupling 70.151 is a high-performance, nickel-plated brass swivel engineered for high-pressure cleaning systems and industrial hose applications. Designed to deliver reliable, leak-free performance under demanding conditions, this swivel features a robust ceramic seal system and a single thrust ball bearing for smooth rotational operation.

The integrated flange allows for quick and secure installation, while built-in weep holes provide a visible warning in the event of seal failure—helping to reduce downtime and maintenance costs. The coupling features a Quick Connect Thread In of M22x1.5 F and a Thread Out of ¼" NPTM, offering wide compatibility with standard hose and equipment fittings.

With a pressure rating up to 3600 PSI, a maximum temperature tolerance of 250°F, and support for pH 3–12 media and 10-micron filtered compressed air (290 PSI), the DKS 70.151 is ideal for use in professional-grade cleaning and connection systems.

Applications

• High-pressure cleaning and spraying systems

• Industrial and commercial hose assemblies

• Quick-connect setups for pressure washers

• Surface cleaning tools and rotary nozzles

• Pneumatic tool connections

• Car wash installations and maintenance equipment

Features

• Nickel-plated brass for corrosion resistance and durability

• Ceramic seal system for long-term performance

• Smooth rotation with single thrust ball bearing

• Flanged design for simple installation

• Built-in weep holes indicate seal failure

• Thread In: M22x1.5 F | Thread Out: ¼" NPTM

• Nominal Width (NW): ¼"

• Max Pressure: 3600 PSI

• Max Temperature: 250°F

• Max RPM: 30

• Dimensions: 1.34" diameter | 1.76" overall length

• Suitable for pH 3–12 media and 10-micron filtered air (290 PSI)

Specs

Pressure: 3600 psi

Temperature: 250°

RPM: max 30 rpm

Material Type: Brass, nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR

Throughput/medium: ph 3-12, filtered 10 microns compressed air (290 psi)

Thread In: G1 M22X1.5F

Thread Out: G2 1/4"NPTM

Nominal Width (NW): ¼"

Wrench Size 1 (SW1): 0.67"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 1.76

Length 2 (L2): 0.43

Weight: 3.7 oz

The Mosmatic DGVI Swivel 32.769 is a premium stainless steel swivel connector designed for high-pressure hose reels, HP-Guns, and hydraulic systems. It features 3/8" NPTF inlet and outlet ports with a single thrust ball bearing, enabling smooth live rotation under maximum pressure.

Crafted with robust stainless steel, this swivel ensures superior corrosion resistance, low maintenance, and long-lasting performance in demanding environments. Ideal for tangle-free hose operations in pressure washing and hydraulic applications.

Applications

• High-pressure hose reels

• Hydraulic systems

• HP-Guns and pressure washers

• Commercial cleaning equipment

• Tangle-free hose installations

Features

• Material: Full stainless steel construction

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTF

• Overall Length: 2.87"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.94"

• Max Pressure: 7300 PSI

• Max RPM: 30

• Max Temperature: 250°F

• Bearing System: 1x thrust ball bearing

• Seal System: O-ring NBR (optional EPDM or FKM)

• Performance: Live rotation, zero maintenance, corrosion resistant

Specs

Pressure: 7300 psi (50 MPa)

Temperature: 250°F

RPM: max 30 rpm

Material Type: Stainless steel

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTF

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.94"

Wrench Size 2 (SW2): 0.87"

Length 1 (L1) (overall length) : 2.87"

Weight: 7.1 oz
