Swivel by Name

The Mosmatic DGG Swivel 33.163 is a high-quality, nickel-plated brass swivel engineered for demanding high-pressure and self-rotating cleaning applications. Designed with precision and durability in mind, it features a triple bearing system (2x radial ball bearings and 1x thrust bearing) for optimized rotational performance and longevity.

This swivel includes a reliable O-ring NBR seal system, with optional upgrades to EPDM or FKM seals for enhanced chemical resistance. Built to be corrosion-resistant and maintenance-free, the DGG 33.163 is ideal for both stationary and rotating systems.

Applications:

• High-pressure cleaning equipment

• Self-rotating surface cleaners

• Parts washers

• Tire and underbody cleaning systems

• Industrial wash systems

Key Features:

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: Triple system – 2x radial, 1x thrust

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): G3/8" M

• Overall Diameter: 1.34"

• Overall Length: 2.59"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Operation: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 G3/8" M

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.59"

Length 2 (L2): 0.39"

Weight: 8.4 oz

The Mosmatic DGG Swivel 33.051 is a premium brass, nickel-plated swivel designed for high-pressure cleaning applications that demand consistent rotation and durability. With a robust construction and triple bearing system, this swivel ensures smooth, maintenance-free operation in self-rotating equipment, parts washers, and tire cleaning systems.

Engineered for maximum precision, this swivel includes a durable O-ring NBR seal system (optional: EPDM or FKM) for optimal sealing under pressure and rotation. Its compact size, corrosion-resistant finish, and ability to perform at high RPMs make it ideal for integration into commercial or industrial cleaning setups.

Applications:

• High-pressure cleaning technology

• Parts and component washers

• Tire and undercarriage cleaners

• Self-rotating spray systems

• Industrial and OEM equipment

Key Features:

• Material: Brass, nickel-plated for corrosion resistance

• Seal System: O-ring NBR (optional: EPDM or FKM)

• Bearing Design: Triple bearing system (2x radial, 1x thrust)

• Mounting: Bulkhead style for secure installation

• Thread IN: 1/4" NPTF

• Thread OUT: 1/4" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.71"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

• Performance: High-precision, maintenance-free operation

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.67"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.71"

Length 2 (L2): 0.43"

Weight: 8.5 oz

The Mosmatic DGG Swivel 33.653 is a high-quality brass, nickel-plated swivel engineered for demanding high-pressure cleaning systems. Ideal for parts washers, tire cleaners, and self-rotating cleaning applications, it offers superior performance and reliability.

This swivel features a triple bearing system with 2x radial ball bearings and 1x thrust ball bearing for long service life and smooth rotation. Designed with an O-ring NBR seal system (also available with optional EPDM or FKM seals), the 33.653 is maintenance-free and corrosion-resistant.

Built for precision and durability, the DGG 33.653 handles up to 4000 PSI, with performance suited for both high-speed and high-temperature applications.

Applications:

• High-pressure cleaning systems

• Self-rotating surface cleaners

• Parts washing systems

• Tire and undercarriage cleaning equipment

• Industrial and automotive cleaning setups

Key Features:

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: Triple bearing system (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.63"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Maximum Pressure: 4000 PSI

• Maximum RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Operation: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.55"

Length 2 (L2): 0.47"

Weight: 7.6 oz

The Mosmatic DGG Swivel 33.153 is a high-precision, nickel-plated brass swivel designed for self-rotating, high-pressure cleaning systems. Built for performance and longevity, it features a triple bearing system—two radial ball bearings and one thrust bearing—for smooth, consistent operation in demanding environments.

This swivel includes an O-ring NBR seal system with optional upgrades to EPDM or FKM for specialized chemical resistance. The corrosion-resistant design, bulkhead mounting, and maintenance-free operation make it ideal for industrial cleaning setups.

Applications:

• High-pressure cleaning systems

• Parts washers

• Self-rotating cleaning heads

• Tire and undercarriage cleaners

• Automated car wash system

Key Features:

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: Triple system (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.59"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM / 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.59"

Length 2 (L2): 0.47"

Weight: 8.5 oz

The Mosmatic DGG Swivel 33.353 (90 Degrees) is a brass, nickel-plated swivel designed for high-pressure, self-rotating cleaning applications. With a durable 90° configuration, it’s perfect for systems requiring compact, directional rotation such as tire cleaners, parts washers, and industrial surface cleaners.

This high-performance swivel features a triple bearing system—2x radial ball bearings and 1x thrust ball bearing—for optimal rotation under pressure. The O-ring NBR seal system ensures leak-free performance, and can be optionally upgraded to EPDM or FKM seals for increased chemical compatibility. Built for corrosion resistance, bulkhead mounting, and maintenance-free operation, the DGG 33.353 ensures reliability in even the harshest cleaning environments.

Applications

• High-pressure rotating cleaning systems

• Parts washing equipment

• Tire and undercarriage cleaning systems

• Industrial surface cleaners

• Self-rotating cleaning heads

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal Type: O-ring NBR (optional EPDM or FKM)

• Bearing System: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 1/4" NPTF

• Thread OUT (G2): 3/8" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting Type: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Length 2 (L2): 0.47"

Weight: 8.5 oz

The Mosmatic DGG Swivel 33.463 (90 Degrees) is a brass, nickel-plated high-pressure swivel engineered for efficient operation in self-rotating and automated cleaning systems. With its compact 90° design and robust construction, it’s the ideal solution for tire cleaning, parts washers, and surface cleaners in industrial or commercial environments.

This swivel features a triple bearing system consisting of 2x radial ball bearings and 1x thrust ball bearing, enabling smooth, controlled rotation under pressure. It includes a reliable O-ring NBR seal system, with optional EPDM or FKM seals for enhanced chemical resistance. Built for corrosion resistance and maintenance-free performance, the DGG 33.463 is designed to withstand high RPMs and pressures in demanding applications.

Applications

• High-pressure rotating cleaning systems

• Tire and underbody washing equipment

• Industrial parts washers

• Surface cleaners and rotating nozzles

• Automated washing systems

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Type: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): G3/8" M

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 G3/8" M

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Length 2 (L2): 0.39"

Weight: 12.1 oz

The Mosmatic DGG Swivel 33.151 is a premium nickel-plated brass swivel engineered for high-pressure and self-rotating cleaning systems. Designed for durability and precision, this swivel incorporates a triple bearing system—including two radial ball bearings and one thrust bearing—to ensure optimal performance and reliability.

Its O-ring NBR sealing system (also available in EPDM or FKM) provides flexibility for varied applications and fluid compatibility. With a corrosion-resistant design and maintenance-free construction, the DGG 33.151 is built to meet the rigorous demands of commercial and industrial cleaning systems.

Applications:

• High-pressure self-rotating cleaning systems

• Undercarriage and tire washers

• Industrial parts washers

• Car wash and fleet wash systems

• Factory and equipment cleaning

Key Features:

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: Triple system – 2x radial, 1x thrust

• Mounting: Bulkhead fitting

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 1/4" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.55"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM; 250°F at 30 RPM

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.67"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.55"

Length 2 (L2): 0.43"

Weight: 7.4 oz

The Mosmatic DGG Swivel 33.351 (90 Degrees) is a high-precision, brass, nickel-plated swivel designed for high-pressure, self-rotating cleaning applications. Built to perform in demanding environments like tire washers, parts cleaning systems, and industrial surface cleaners, this swivel ensures longevity and efficiency.

Featuring a compact 90-degree angle design, it includes a triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth, reliable operation. The swivel is sealed with a dependable O-ring NBR system, with optional upgrades to EPDM or FKM for chemical resistance. Designed for corrosion resistance, easy bulkhead mounting, and maintenance-free use, the 33.351 delivers long-term durability and exceptional precision.

Applications

• High-pressure rotating cleaning systems

• Tire and underbody cleaning equipment

• Parts washers and degreasers

• Industrial wash stations

• Surface cleaners and sprayers

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Type: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 1/4" NPTF

• Thread OUT (G2): 1/4" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.71"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting Style: Bulkhead

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 1/4" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.67"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.71"

Length 2 (L2): 0.43"

Weight: 7.8 oz

The Mosmatic DGG Swivel 33.063 is a high-performance brass, nickel-plated swivel engineered for high-pressure cleaning applications and self-rotating equipment. With a triple bearing system (2x radial and 1x thrust bearing), this swivel ensures smooth, low-resistance rotation and long-lasting performance.

It features a durable O-ring NBR seal system, with optional EPDM or FKM seal materials available for varied environmental compatibility. The bulkhead mount design allows secure integration into tire washers, parts cleaners, or other automated systems.

Applications:

• Self-rotating cleaning heads

• Tire and wheel cleaning systems

• High-pressure parts washers

• Stationary and mobile wash equipment

• Rotating spray arm assemblies

Key Features:

• Material: Brass, nickel-plated for durability and corrosion resistance

• Seal System: O-ring NBR (optional EPDM or FKM for added chemical resistance)

• Bearings: Triple bearing configuration (2x radial, 1x thrust)

• Mounting: Bulkhead design for secure installation

• Thread IN: 1/4" NPTF

• Thread OUT: G3/8" M

• Overall Diameter: 1.34"

• Overall Length: 2.59"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Maximum Pressure: 4000 PSI

• Maximum RPM: 1000

• Maximum Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

• Maintenance: Maintenance-free, high-precision operation

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 G3/8" M

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.59"

Length 2 (L2): 0.39"

Weight: 8.7 oz

The Mosmatic DGG Swivel 33.052 is a high-performance brass, nickel-plated swivel designed for self-rotating, high-pressure cleaning applications. Ideal for use in tire cleaners, parts washers, and surface cleaners, this swivel ensures long-lasting precision and efficiency.

Equipped with a triple bearing system—including two radial ball bearings and one thrust ball bearing—the 33.052 delivers smooth rotation under high pressure. The O-ring NBR seal system provides a reliable seal, with optional EPDM or FKM materials available for specialized needs. Its corrosion-resistant construction and bulkhead fitting make it a top-tier, maintenance-free solution for industrial cleaning setups.

Applications:

• High-pressure cleaning systems

• Self-rotating cleaning equipment

• Parts washers

• Tire and underbody cleaners

• Industrial degreasing stations

Key Features:

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Design: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 1/4" NPTF

• Thread OUT (G2): 1/4" NPTF

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 1/4" NPTF

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Weight: 7.4 oz

The Mosmatic DGG Swivel 33.453 (90 Degrees) is a brass, nickel-plated high-pressure swivel engineered for self-rotating and high-performance cleaning systems. Designed for use in parts washers, tire cleaners, and surface cleaning machines, it delivers premium performance in compact and demanding environments.

Featuring a durable 90° angled body, this swivel integrates a triple bearing system—two radial ball bearings and one thrust bearing—for smooth and consistent rotation. The O-ring NBR seal system ensures reliable leak resistance and is optionally available with EPDM or FKM seals for improved chemical compatibility. With its bulkhead mounting design, corrosion resistance, and maintenance-free construction, the 33.453 is built for longevity and precision in high-RPM, high-pressure use.

Applications

• High-pressure cleaning equipment

• Tire and underbody cleaning systems

• Parts washers and degreasers

• Industrial self-rotating nozzles

• Automated surface cleaning equipment

Key Features

• Design: 90° angled swivel

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing Configuration: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting Type: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Length 2 (L2): 0.47"

Weight: 10.7 oz

The Mosmatic DGGI Swivel 33.907 is a high-precision stainless steel swivel designed for high-pressure cleaning systems and self-rotating equipment. Engineered for durability and performance, this swivel features a triple bearing system—two radial and one thrust bearing—for smooth operation and extended service life.

Its O-ring NBR seal system (with optional EPDM or FKM alternatives) ensures excellent sealing performance under a variety of temperatures and pressures. This swivel is corrosion-resistant, maintenance-free, and ideal for applications requiring reliability at high speeds and pressures.

Applications:

• Self-rotating high-pressure cleaning systems

• Tire and undercarriage washers

• Industrial parts washers

• Wash bays and automated wash systems

• Food-grade and chemical wash-down equipment

Key Features:

• Material: High-grade stainless steel for corrosion resistance and hygiene-critical applications

• Seal Type: O-ring NBR standard (EPDM or FKM optional for chemical compatibility)

• Bearing System: Triple bearing setup (2x radial, 1x thrust) for high-speed rotation

• Mounting Type: Bulkhead fitting for secure and stable installation

• Thread Inlet (G1): 1/4" NPTF

• Thread Outlet (G2): G3/8" M

• Overall Diameter: 1.42"

• Overall Length: 2.59"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI (276 bar)

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM; 250°F at 30 RPM

• Maintenance: 100% maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Stainless steel

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 G3/8" M

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.42"

Diameter (D) (overall diameter): 1.42"

Length 1 (L1) (overall length) : 2.59"

Length 2 (L2): 0.39"

Weight: 8.7 oz

The Mosmatic DGG Swivel 33.154 is a durable, high-performance brass swivel engineered for high-pressure and self-rotating cleaning applications. Ideal for parts washers, tire cleaners, and industrial wash systems, this swivel ensures reliable performance with minimal maintenance.

It features a triple bearing system—two radial ball bearings and one thrust ball bearing—for smooth and consistent rotation. The integrated O-ring NBR seal system offers secure sealing and is optionally available with EPDM or FKM materials for enhanced chemical resistance. The nickel-plated finish provides corrosion resistance, and the bulkhead design allows for easy mounting and long-term use in harsh environments.

Applications

• High-pressure cleaning systems

• Parts washing machines

• Self-rotating cleaning heads

• Tire and undercarriage washers

• Industrial wash bays and equipment

Key Features

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing System: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 3/8" NPTF

• Overall Diameter: 1.34"

• Overall Length: 2.87"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 3/8" NPTF

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.87"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.87"

Weight: 8.8 oz

The Mosmatic DGG Swivel 33.152 is a precision-engineered brass, nickel-plated swivel built for demanding high-pressure cleaning and self-rotating applications. This swivel is ideal for use in tire cleaners, industrial parts washers, and automated cleaning equipment.

Its advanced triple bearing system—featuring two radial ball bearings and one thrust ball bearing—ensures smooth, reliable rotation even under continuous high pressure. The O-ring NBR sealing system offers dependable leak resistance and can be optionally configured with EPDM or FKM seals for chemical compatibility. Corrosion-resistant and maintenance-free, this swivel is designed for long-lasting performance in tough environments.

Applications

• High-pressure cleaning systems

• Parts washers

• Self-rotating cleaning heads

• Tire and underbody wash systems

• Industrial automated cleaning equipment

Key Features

• Material: Brass, nickel plated

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearing System: Triple bearing (2x radial, 1x thrust)

• Thread IN (G1): 3/8" NPTF

• Thread OUT (G2): 1/4" NPTF

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature:

  • 90°F at 1000 RPM

  • 250°F at 30 RPM

• Mounting Type: Bulkhead fitting

• Maintenance: Maintenance-free

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 3/8" NPTF

Thread Out: G2 1/4" NPTF

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Weight: 8.7 oz

The Mosmatic DGG Swivel 33.053 is a premium brass, nickel-plated swivel designed for high-pressure cleaning systems and self-rotating applications. Its triple bearing design (2x radial, 1x thrust) ensures optimal rotation and extended performance in demanding environments.

Featuring an O-ring NBR seal system (with optional EPDM or FKM upgrades), this swivel is built to resist corrosion and withstand high temperatures and pressure. With a bulkhead-style mounting, it’s easy to integrate into tire cleaners, parts washers, and other industrial cleaning setups.

Applications:

• Self-rotating high-pressure cleaning systems

• Tire and wheel washers

• Industrial parts cleaning equipment

• Stationary or automated wash systems

• Spray arms and nozzle assemblies

Key Features:

• Material: Brass, nickel plated for corrosion resistance

• Seal System: O-ring NBR (optional EPDM or FKM)

• Bearings: Triple bearing system (2x radial, 1x thrust)

• Mounting: Bulkhead design for secure installation

• Thread IN: 1/4" NPTF

• Thread OUT: 3/8" NPTM

• Overall Diameter: 1.34"

• Overall Length: 2.75"

• Nominal Width (NW): 1/4"

• Wrench Size (SW): 0.87"

• Max Pressure: 4000 PSI

• Max RPM: 1000

• Max Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

• Performance: Maintenance-free, high-precision operation

Specs

Pressure: 4000 psi (27.5 MPa)

Temperature: 90°F at 1000 RPM, 250°F at 30 RPM

RPM: max 1,000 rpm

Material Type: Brass, Nickel plated

Inner Part: Stainless steel

Seal: O-ring NBR (optional: EPDM or FKM)

Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)

Thread In: G1 1/4" NPTF

Thread Out: G2 3/8" NPTM

Nominal Width (NW): 1/4"

Wrench Size 1 (SW1): 0.87"

Wrench Size 2 (SW2): 0.75"

Wrench Size 3 (SW3): 1.34"

Diameter (D) (overall diameter): 1.34"

Length 1 (L1) (overall length) : 2.75"

Length 2 (L2): 0.47"

Weight: 7.4 oz
