Product Description
The Mosmatic DGV Face Seal 32.871 is a durable brass, nickel-plated face seal designed for reliable use in high-pressure cleaning and hydraulic systems. With 13/16”-16UN thread connections on both ends, this high-performance connector delivers secure, leak-free sealing in HP-Gun assemblies, hose lines, and tangle-free hydraulic applications. Built for live rotation under maximum pressure, it features a single thrust ball bearing system and an NBR O-ring seal (optional upgrades: EBDM or FKM). This face seal ensures maintenance-free operation, excellent corrosion resistance, and seamless hose movement at up to 4000 PSI.
Applications
-
High-pressure gun and hose connections
-
Hydraulic circuits and systems
-
Industrial cleaning tools
-
Hose reels and tangle-free hose setups
-
Commercial pressure washer assemblies
Features
-
Type: Face Seal Connector
-
Material: Brass, nickel plated
-
Thread IN/OUT: 13/16”-16UN
-
Overall Length: 2.44”
-
Nominal Width (NW): 3/8”
-
Wrench Size (SW): 1.06”
-
Max Pressure: 4000 PSI
-
Max Temperature: 250°F
-
Seal Type: O-ring NBR (optional EBDM/FKM)
-
Performance: Live rotation under pressure, corrosion resistant, and maintenance free
Specs
Pressure: 4000 psi (27.5 MPa)
Temperature: 250°F
RPM: max 30 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: O-ring NBR (optional: EPDM or FKM)
Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
Thread In: G1 13/16" 16UN
Thread Out: G2 13/16" 16UN
Nominal Width (NW): 3/8”
Wrench Size 1 (SW1): 1.06"
Wrench Size 2 (SW2): 0.94"
Length 1 (L1) (overall length) : 2.44"
Length 2 (L2): 0.43"
Length 3 (L3): 0.43"
Weight: 6.6 oz
